PRODUCT DESCRIPITION
ASTM standard 0.5mm 1mm smooth HDPE geomembrane dam liner for fish
pond
Geomembrane is the most widely used products for solid waste
containment, mining and water containment applications. is made from
polyethylene resins materials by blowmolding process.According to the different raw materials,
Geomembrane can be divided into:HDPE geomembrane,LDPE Geomembrane, EVA Geomembrane and PVC
Geomembrane,etc.
TECHNICAL DATA
ASTM standard 0.5mm 1mm smooth HDPE geomembrane dam liner for fish
pond
| Thickness | 0.75 | 1.0 | 1.25 | 1.5 | 2.0 | 2.5 | 3.0 |
Density g/m2 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 | ≥0.94 |
Tensile yield strength (N/mm) | ≥11 | ≥15 | ≥18 | ≥22 | ≥29 | ≥37 | ≥44 |
Tensile breaking strength (N/mm) | ≥20 | ≥27 | ≥33 | ≥40 | ≥53 | ≥67 | ≥80 |
Bongation at yield(%) | ≥12 | ≥12 | ≥12 | ≥12 | ≥12 | ≥12 | ≥12 |
Elongation at break(%) | ≥700 | ≥700 | ≥700 | ≥700 | ≥700 | ≥700 | ≥700 |
Tear resistance(N) | ≥93 | ≥125 | ≥160 | ≥190 | ≥250 | ≥315 | ≥375 |
Puncture strength(N) | ≥240 | ≥320 | ≥400 | ≥480 | ≥640 | ≥800 | ≥960 |
Tensile load stress cracking | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 |
Carbon black content(%) | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 | 2.0-3.0 |
APPLICATION
1. Environmental protection:solid waste landfills, sewage treatment plants, power plants
,industrial and hospital waste treatment,hazardous waste landfills,
etc.
2. Water: rivers, lakes,reservoirs,channels,water pond,floating covers,waste
water treatment, etc.
3.Aquaculture:fish pond and shrimp pond,golf course, etc.
4. Petrochemical :chemical plants, oil refineries, gas storage tanks,anti-chemical
reaction tanks, etc.
5. Mining:washing and heap leach ponds, dams,evaporation pond,brine pond.salt
pond, etc..
OUR FACTORY
ASTM standard 0.5mm 1mm smooth HDPE geomembrane dam liner for fish
pond
Taian Wantong Composite Material Co., ltd is located in Taian ,we
are a manufactutre of all kinds of geocomposites products, our main
products including ;
♠Geomembrane series (HDPE,LDPE,LLDPE,EVA,PVC,etc)
♠Geotextile series(PP,PET,etc)
♠Geogrid seres(PP/HDPE,Fiberglass,Polyester ,Steel -plastic ,etc)
♠Geocell,Geonet ,Geomat
♠Composite drainage net,
♠Grass grid
♠Drainage board
♠Geosynthetic clay liners ,
♠Waterproof membrane series (PVC ,EPDM ,TPO,etc)
♠Fiberglass-polyester paving mat ,
♠Geocomposites and so on ,we also have advanced equipment , so if
you have interesting welcome to our factory to visiting and
negotiating , we wish to cooperate sincerely with friends at home
and abroad ,paint the grand blueprint and create brillance together
.
PACKAGING AND DELIVERY
Packaging : standard package or according to customer's requirment
delibery : 10 days after received the deposite
PRODUCTION FLOW
ASTM standard 0.5mm 1mm smooth HDPE geomembrane dam liner for fish
pond
OUR SERVICES AND EXHIBITION
Quality assurance
1. On a regular basis or as per your request,we entrust national
testing agencies to conduct quality inspections
2.Strictly in accordance with the ISO9001-2008 international quality
system standard,we monitor and manage the whole process throughout
production,quality testing,and measurement to ensure product
quality
3. For quality-related construction delay or substandard
construction(except for damage or losses due to customer’s
responsibility or irresistible natural disasters),we have
refunding,replacement,and repair services.We will respond to
customers’ feedbacks on quality issues within 24 hours.
OUR CERTIFICATION
FAQ
1.How about the delivery time?
after 10 days since receipt of 30% T/T deposit
2.What kind of payments does jenor support?
T/T
3.What's are the MOQ?
We can according to your condition to set the MOQ.
And we can provide you samples for quality inspection.
4.How to deal with the sample charge?
According to our company policy, the samples are free, we only
charge the freight fee.
And we will return the freight fee If you set the order .
5.Can you produce the product according to customers' requirements ?
Sure, we are professional manufacturer, OEM and ODM are both
welcome.
